Wood Surface Planer Sander Wood Curvature Planer Molding Sanding Machine For Sale

Wood Surface Planer Sander Wood Curvature Planer Molding Sanding Machine For Sale
Name:Wood Surface Planer Sander
Brand:Innold
Working Width:630MM/1000MM/1300MM
Working Thickness:2-200MM
1# Sanding Belt Speed:18M/MIN
2# Sanding Belt Speed:12M/MIN
Conveyor Belt Height:5-25m/s
Stroke Height:120-200mm
Operating Air Pressure:0.5Mpa
Suction Air Speed:25m/s
Suction Air Volume:5000m³/h
Delivery time: 7-15 days
Warranty period: 1 year

Product Details

Product Tags

Wood Surface Planer Sander Wood Curvature Planer Molding Sanding Machine For Sale

Wood Surface Planer Sander

Curvature Sander is a specialized piece of equipment designed to "beautify" the surface of wood. It makes the wood surface smoother, finer, and gives it a better shine. Simply put, it removes small imperfections from the wood surface, making the wood grain appear smoother and preparing it for subsequent processes such as painting and veneer.

These machines are commonly found in furniture factories, panel processing plants, and woodworking workshops. With them, the quality of the wood surface is more guaranteed, production efficiency is greatly improved, and the final products are more professional and beautiful.

SpecificationsD-RP630D-RP1000D-RP1300
Working Width630mm1000mm1300mm
Working Thickness2-200mm2-200mm2-120mm
1# Sanding Belt Speed18m/min18m/min18m/min
2# Sanding Belt Speed14m/min12m/min12m/min
Conveyor Belt Height5-25m/s5-25m/s5-25m/s
Sanding Belt Dimensions650*1920mm1020*2020mm1320*2020mm
Total Motor Power20.37-35.37kw20.77-38.87kw56.55-75.55kw
Stroke Height120-200mm120-200mm120-200mm
Operating Air Pressure0.5Mpa0.6Mpa0.6Mpa
Suction Air Speed25m/s25m/s25m/s
Suction Air Volume5000m³/h5000m³/h5000m³/h
Dimensions1700*1100*2050mm1700*1400*2050mm2700*2200*2050mm
Net Weight1000kg2000kg3000kg

What exactly is a Door Window Sanding Machine?

It's essentially an industrial machine that uses sanding belts, rollers, or polishing wheels to sand and polish the surface of wood.

Its main functions are:

1. Removing rough parts from the wood surface.

2. Cleaning away residual glue.

3. Eliminating minor imperfections.

4. Creating a smooth, even surface before painting or applying other coatings.

Therefore, it's indispensable in:

1- Furniture factories.

2- Wood panel processing plants.

3- Cabinet and door manufacturers.

4- Flooring production workshops.

Wood Surface Planer Sander

What types of wood can be used for processing by Wood Planer?

1. Various solid wood panels.

2. Common plywood.

3. Medium-density fiberboard (MDF).

4. Particleboard.

5. Veneered panels.

6. Various decorative wood panels.

What products can be made from Wood Planer For Sale?

1. Furniture panels.

2. Cabinet doors.

3. Wooden tables and chairs.

4. Interior doors.

5. Wood flooring.

6. Various decorative wood panels.

Wood Surface Planer SanderWood Surface Planer SanderWood Surface Planer Sander

What are the features and advantages of a Molding Sanding Machine?

1. High surface treatment precision: It adopts an advanced sanding system to ensure a smooth and uniform wood surface without damaging the wood's structure.

2. Suitable for industrial production: This machine is specifically designed for continuous factory production, offering stable performance and high efficiency.

3. Adjustable sanding thickness: It allows for precise control of how much material is removed each time, depending on the type and thickness of the wood.

4. Wide-band sanding system: It can achieve a uniform sanding effect across the entire width of the board.

5. Powerful motor: Equipped with a high-power motor, it provides sufficient sanding power even for harder woods.

6. Dust collection system compatible: It can be connected to a dust collection system to maintain a clean working environment.

What are the functions of Multi Head Sander?

The wood sanding and polishing machine mainly has these basic functions:

Surface sanding: Removes rough parts from the wood surface.

Wood polishing: Makes the wood surface smoother and more delicate.

Thickness calibration: Adjusts the thickness of the wood to meet standards.

Preparing for fine surface finishing: Laying the foundation for subsequent painting, veneer, and other processes.

Removing imperfections: Eliminating surface defects in the wood.

In addition, there are some optional functions:

Double-sided sanding: Sanding both sides of the wood simultaneously.

Fine polishing system: Further enhancing the gloss of the wood surface.

Automatic thickness adjustment: Automatically adjusting the sanding thickness for greater convenience and speed.

Digital control panel: Setting and controlling various machine parameters via the digital control panel.

  How does Surface Wood Planer work?

1. First, the wood planks are placed on the feed conveyor.

2. The conveyor delivers the planks to the sanding section.

3. The sanding belt or rollers begin working, removing uneven areas from the wood surface.

4. The polishing wheel performs fine sanding, making the surface smoother.

5. Finally, the finished wood plank surface becomes smooth and uniform.

Wood Surface Planer Sander
